Mini Multifunctional Cross Working Table/ slide table support For Drilling Milling Machine Bench drill stent Tools 1PC
Picture showing:
Description:
The table is suitable for Mini Drill and drill bracket series. It can also apply to other suitable machine. The work table is composed of several adjustable dovetail slot aluminum alloy composition, can guarantee the minimum space and ensure the accuracy. The working table with three T shaped groove groove, standard size is 15X8X6mm. Scale is in front of the movable positioning. Zero adjustment handwheel rotates a circle of 1.25mm. A lattice is equal to 0.05mm. The X axis Y axis distance is 200mm, the stroke is 50mm. Working table size is 310X90mm and the height of 80mm, including two working clamp.
